90 Control panels
How to get help
How to find out the panel version
Step Action Display
1. Press to read the context-sensitive help text for the
item that is highlighted.
If help text exists for the item, it is shown on the display.
2. If the whole text is not visible, scroll the lines with keys
and .
3. After reading the text, return to the previous display by
pressing .
Step Action Display
1. If the power is switched on, switch it off.
2. Keep key pressed down while you switch on the
power and read the information. The display shows the
following panel information:
Panel SW: panel firmware version
ROM CRC: panel ROM check sum
Flash Rev: flash content version
Flash content comment.
When you release the key, the panel goes to the
Output mode.
?
01 OPERATING DATA
03 FB ACTUAL SIGNALS
04 FAULT HISTORY
10 START/STOP/DIR
11 REFERENCE SELECT
EXIT SEL
00:00
LOC
PAR GROUPS 10
This group defines
external sources
(EXT1 and EXT2) for
commands that enable
start, stop and
EXIT
00:00
LOC
HELP
external sources
(EXT1 and EXT2) for
commands that enable
start, stop and
direction changes.
EXIT
00:00
LOC
HELP
EXIT
01 OPERATING DATA
03 FB ACTUAL SIGNALS
04 FAULT HISTORY
10 START/STOP/DIR
11 REFERENCE SELECT
EXIT
SEL00:00
LOC
PAR GROUPS 10
?
?
PANEL VERSION INFO
Panel SW: x.xx
Rom CRC: xxxxxxxxxx
Flash Rev: x.xx
xxxxxxxxxxxxxxxxxxxxx
