Actual signals and parameters 187
0303 FB STS WORD
1
A 16-bit data word. See section DCU communication profile
on page 333.
0304 FB STS WORD
2
A 16-bit data word. See section DCU communication profile
on page 333
0305 FAULT WORD
1
A 16-bit data word. For the possible causes and remedies
and fieldbus equivalents, see chapter Fault tracing on page
349.
Bit 0 = OVERCURRENT
Bit 1 = DC OVERVOLT
Bit 2 = DEV OVERTEMP
Bit 3 = SHORT CIRC
Bit 4 = Reserved
Bit 5 = DC UNDERVOLT
Bit 6 = AI1 LOSS
Bit 7 = AI2 LOSS
Bit 8 = MOT OVERTEMP
Bit 9 = PANEL LOSS
Bit 10 = ID RUN FAIL
Bit 11 = MOTOR STALL
Bit 12 = CB OVERTEMP
Bit 13 = EXT FAULT 1
Bit 14 = EXT FAULT 2
Bit 15 = EARTH FAULT
0306 FAULT WORD
2
A 16-bit data word. For the possible causes and remedies
and fieldbus equivalents, see chapter Fault tracing on page
349.
Bit 0 = UNDERLOAD
Bit 1 = THERM FAIL
Bit 2…3 = Reserved
Bit 4 = CURR MEAS
Bit 5 = SUPPLY PHASE
Bit 6 = ENCODER ERR
Bit 7 = OVERSPEED
Bit 8…9 = Reserved
Bit 10 = CONFIG FILE
Bit 11 = SERIAL 1 ERR
Bit 12 = EFB CON FILE. Configuration file reading error.
Bit 13 = FORCE TRIP
Actual signals
No. Name/Value Description FbEq
