190 Actual signals and parameters
0406 VOLTAGE AT
FLT
Intermediate circuit voltage in V DC at the time the latest
fault occurred
1 = 0.1 V
0407 CURRENT AT
FLT
Motor current in A at the time the latest fault occurred 1 = 0.1 A
0408 TORQUE AT
FLT
Motor torque as a percentage of the motor nominal torque
at the time the latest fault occurred
1 = 0.1%
0409 STATUS AT
FLT
Drive status in hexadecimal format at the time the latest
fault occurred
0412 PREVIOUS
FAULT 1
Fault code of the 2nd latest fault. See chapter Fault tracing
on page 349 for the codes.
1 = 1
0413 PREVIOUS
FAULT 2
Fault code of the 3rd latest fault. See chapter Fault tracing
on page 349 for the codes.
1 = 1
0414 DI 1-5 AT FLT Status of digital inputs DI1…5 at the time the latest fault
occurred.
Example (panel):
• 10000 = DI1 is on, DI2…DI5 are off.
• 10010 = DI1 and DI4 are on, DI2, DI3 and DI5 are off.
Example (DWL2):
• 16 (decimal) = DI1 is on, DI2…DI5 are off.
• 18 (decimal) = DI1 and DI4 are on, DI2, DI3 and DI5 are
off.
Actual signals
No. Name/Value Description FbEq
