428 Appendix: Safe torque off (STO)
• The following temperature profile is used in safety value calculations:
• 670 on/off cycles per year with T = 71.66 °C
• 1340 on/off cycles per year with T = 61.66 °C
• 30 on/off cycles per year with T = 10.0 °C
Type
ACS355-
Frame
size
EN ISO 13849-1 IEC/EN
62061
IEC 61511
PL CCF
(%)
MTTF
d
1
(a)
DC
2
(%)
Category SILCL SIL
1-phase U
N
= 200…240 V (200, 208, 220, 230, 240 V)
01x-02A4-2 R0 e 80 3419 >90% 3 3 3
01x-04A7-2 R1 e 80 3419 >90% 3 3 3
01x-06A7-2 R1 e 80 3419 >90% 3 3 3
01x-07A5-2 R2 e 80 3491 >90% 3 3 3
01x-09A8-2 R2 e 80 3491 >90% 3 3 3
3-phase U
N
= 200…240 V (200, 208, 220, 230, 240 V)
03x-02A4-2 R0 e 80 3419 >90% 3 3 3
03x-03A5-2 R0 e 80 3419 >90% 3 3 3
03x-04A7-2 R1 e 80 3419 >90% 3 3 3
03x-06A7-2 R1 e 80 3419 >90% 3 3 3
03x-07A5-2 R1 e 80 3419 >90% 3 3 3
03x-09A8-2 R2 e 80 3491 >90% 3 3 3
03x-13A3-2 R2 e 80 3491 >90% 3 3 3
03x-17A6-2 R2 e 80 3491 >90% 3 3 3
03x-24A4-2 R3 e 80 3488 >90% 3 3 3
03x-31A0-2 R4 e 80 3486 >90% 3 3 3
03x-46A2-2 R4 e 80 3486 >90% 3 3 3
3-phase U
N
= 380…480 V (380, 400, 415, 440, 460, 480 V)
03x-01A2-4 R0 e 80 3491 >90% 3 3 3
03x-01A9-4 R0 e 80 3491 >90% 3 3 3
03x-02A4-4 R1 e 80 3491 >90% 3 3 3
03x-03A3-4 R1 e 80 3491 >90% 3 3 3
03x-04A1-4 R1 e 80 3491 >90% 3 3 3
03x-05A6-4 R1 e 80 3491 >90% 3 3 3
03x-07A3-4 R1 e 80 3491 >90% 3 3 3
03x-08A8-4 R1 e 80 3491 >90% 3 3 3
03x-12A5-4 R3 e 80 3488 >90% 3 3 3
03x-15A6-4 R3 e 80 3488 >90% 3 3 3
03x-23A1-4 R3 e 80 3488 >90% 3 3 3
03x-31A0-4 R4 e 80 3486 >90% 3 3 3
03x-38A0-4 R4 e 80 3486 >90% 3 3 3
03x-44A0-4 R4 e 80 3486 >90% 3 3 3
3AXD00000353783.xls L
1
100 years must be used for calculation of a safety loop.
2
According to standard EN ISO 13849-1 table E.1
