14.10 Signal/trip output with high make and carry and
with TCS function
Table 1094: Signal/trip output with high make and carry and with TCS function
Description Value
1
Rated voltage 250 V AC/DC
Continuous contact carry 5 A
Make and carry for 3.0 s 15 A
Make and carry for 0.5 s 30 A
Breaking capacity when the control-circuit
time constant L/R < 40 ms, at 48/110/220
V DC (two contacts connected in series)
1 A/0.25 A/0.15 A
Minimum contact load 100 mA at 24 V AC/DC
1
X130: SO3 of RET620 equipped with RTD0002
