3.1.7 Binary signals in card location Xnnn
Table 12: Binary input signals in card location Xnnn
Name Type Description
Xnnn-Input m
1
,
2
BOOLEAN See the application manual
for terminal connections
Table 13: Binary output signals in card location Xnnn
Name Type Default Description
Xnnn-Pmm
1
,
3
BOOLEAN 0=False See the application
manual for terminal
connections
1
Xnnn = Slot ID, for example, X100, X110, as applicable
2
m =For example, 1, 2, depending on the serial number of the binary input in a particular BIO card
3
Pmm = For example, PO1, PO2, SO1, SO2, as applicable
