5.6.7 Settings
Table 805: CVPSOF Non group settings (Basic)
Parameter Values (Range) Unit Step Default Description
Operation
1=on
5=off
1=on
Operation Off / On
Table 806: CVPSOF Non group settings (Advanced)
Parameter Values (Range) Unit Step Default Description
Operation mode
1=Start
2=Current&voltage
3=Both
3=Both
Mode of operation
of SOTF Function
Automatic SOTF Ini
1=DLD disabled
2=Voltage
3=Current
4=Current&voltage
2=Voltage
Automatic switch
onto fault initializa-
tion
Current dead Lin
Val
0.01...1.00 xIn 0.01 0.20 Dead line value,
current. Used also
in auto activation
logic
Voltage dead Lin
Val
0.01...0.58 xUn 0.01 0.40 Dead line value,
voltage. Used also
in auto activation
logic
Cur voltage Det
time
0...60000 ms 10 20 Time delay for volt-
age and current
based detection
Operate time delay 0...120000 ms 10 20 Delay for the de-
layed start input
SOTF reset time 0...60000 ms 10 1000 SOTF detection pe-
riod after initializa-
tion
Dead line time 0...60000 ms 10 200 Delay time for acti-
vation of dead line
detection
5.6.8 Monitored data
Table 807: CVPSOF Monitored data
Name Type Values (Range) Unit Description
CVPSOF Enum
1=on
2=blocked
3=test
4=test/blocked
5=off
Status
