ABB Relion 620 Series - IEC 61850-8-1 MMS Settings

Parameter Values (Range) Unit Step Default Description
Frame4InUse
-1=Not in use
0=User frame
1=Standard frame 1
2=Standard frame 2
3=Standard frame
3
4=Standard frame
4
5=Standard frame
5
6=Private frame 6
7=Private frame 7
-1=Not in use Active Class2
Frame 4
Class1OvInd
0=No indication
1=Both edges
2=Rising edge
2=Rising edge Overflow Indication
Class1OvFType 0...255 1 10 Function Type for
Class 1 overflow in-
dication
Class1OvInfNo 0...255 1 255 Information Num-
ber for Class 1 over-
flow indication
Class1OvBackOff 0...500 1 500 Backoff Range for
Class1 buffer
GI Optimize
0=Standard behav-
iour
1=Skip spontane-
ous
2=Only overflown
3=Combined
0=Standard behav-
iour
Optimize GI traffic
DR Notification
0=False
1=True
0=False Disturbance Re-
corder spontane-
ous indications en-
abled/disabled
Block Monitoring
0=Not in use
1=Discard events
2=Keep events
0=Not in use Blocking of Moni-
toring Direction
Internal Overflow
0=False
1=True
0=False Internal Overflow:
TRUE-System level
overflow occured
(indication only)
EC_FRZ
0=False
1=True
0=False Control point for
freezing energy
counters
