3.13.5 Monitored data
Table 61: 6RTD/2mA monitored data
Name Type Values (Range) Unit Description
AI_DB1 FLOAT32 -10000.0...10000.
0
mA input, Con-
nectors 1-2, re-
ported value
AI_RANGE1 Enum
0=normal
1=high
2=low
3=high-high
4=low-low
mA input, Con-
nectors 1-2,
range
AI_DB2 FLOAT32 -10000.0...10000.
0
mA input, Con-
nectors 3-4, re-
ported value
AI_RANGE2 Enum
0=normal
1=high
2=low
3=high-high
4=low-low
mA input, Con-
nectors 3-4,
range
AI_DB3 FLOAT32 -10000.0...10000.
0
RTD input, Con-
nectors 5-6-11c,
reported value
AI_RANGE3 Enum
0=normal
1=high
2=low
3=high-high
4=low-low
RTD input, Con-
nectors 5-6-11c,
range
AI_DB4 FLOAT32 -10000.0...10000.
0
RTD input, Con-
nectors 7-8-11c,
reported value
AI_RANGE4 Enum
0=normal
1=high
2=low
3=high-high
4=low-low
RTD input, Con-
nectors 7-8-11c,
range
AI_DB5 FLOAT32 -10000.0...10000.
0
RTD input, Con-
nectors 9-10-11c,
reported value
Table continues on the next page
