ABB Relion 620 Series - Page 781

Parameter Values (Range) Unit Step Default Description
Alarm delay time 500...6000000 ms 100 300000 Alarm delay time
Un Cur delay time 100...120000 ms 100 1000 Delay time for un-
der current opera-
tion
Table 742: COLPTOC Group settings (Advanced)
Parameter Values (Range) Unit Step Default Description
Reclose inhibit time 1...6000 s 1 1 Reclose inhibit time
Table 743: COLPTOC Non group settings (Basic)
Parameter Values (Range) Unit Step Default Description
Operation
1=on
5=off
1=on Operation Off / On
Reclose inhibit
mode
1=Non-latched
3=Lockout
1=Non-latched Reclose inhibit
mode
Num of start pha-
ses
1=1 out of 3
2=2 out of 3
3=3 out of 3
1=1 out of 3 Number of phases
required for oper-
ate activation
Table 744: COLPTOC Non group settings (Advanced)
Parameter
Values (Range) Unit Step Default Description
Enable under cur-
rent
0=Disable
1=Enable
1=Enable Enable under cur-
rent functionality
4.12.1.8 Monitored data
Table 745: COLPTOC Monitored data
Name
Type Values (Range) Unit Description
ST_DUR_OVLOD FLOAT32 0.00...100.00 % Start duration for over-
load stage
ST_DUR_UN_I FLOAT32 0.00...100.00 % Start duration for under
current operation
I_PEAK_INT_A FLOAT32 0.00...40.00 Phase A peak value of
the integrated current
of the capacitor
I_PEAK_INT_B FLOAT32 0.00...40.00 Phase B peak value of
the integrated current
of the capacitor
I_PEAK_INT_C FLOAT32 0.00...40.00 Phase C peak value of
the integrated current
of the capacitor
COLPTOC Enum
1=on
2=blocked
3=test
4=test/blocked
5=off
Status
