KNX control elements and application parameters
Application "Logical functions"
Product manual 2CKA001473B5343
222
If the size of the input and output objects is 1 bit, the input can also be inverted. This allows
an inverting member to be implemented via a gate. It is also possible to block signals via the
"Filter function" setting. Either "Do not filter" or the signal "Filtered out ON" or the signal
"Filtered out OFF" is sent.
The following parameters are displayed:
Direction of data flow:
Options: Input -> Output
Output -> Input
Input <-> Output
The parameter is used to specify the direction data are sent via the channel. See the
explanation above.
Sending an output telegram:
Options: At every receipt
At changed values
The parameter is used to specify when the output telegram is sent.
Control input:
Options: Activation at OFF
Activation at ON
See the explanation above.
Object type input/output:
Options: Switch
Forced operation
1-byte value [0% - 100%]
1-byte value [0 - 255]
1-byte value [-128 - 127]
Scene number
RTC operating mode
Temperature
2-byte value [-32768 - +32767]
2-byte value [0 - 65535]
2-byte floating point
4-byte value [-2147483648 - 2147483647]
4-byte value [0 - 4294967295]
14-byte text
The parameter is used to specify the size of the communication object.
– Switch: The following supplementary parameters are available:
Inverting an input:
Options: Deactivated
Activated
The parameter is used to specify whether the switching input is inverted.
Filter function:
Options: Do not filter
