KNX control elements and application parameters
Application "Logical functions"
Product manual 2CKA001473B5343
223
Filter 0
Filter 1
See the explanation above.
– Forced operation: Management systems can access the device directly via KNX.
However, it can also be specified that one can select manually (forced operation) via
buttons. No additional parameters available.
– 1-byte value [0% - 100%]: A value is sent as 1-byte value without a sign (percentage
value). No additional parameters available.
– 1-byte value [0 - 255]: A value is sent as 1-byte value without a sign, e.g. actuating
value, angle or brightness value. No additional parameters available.
– 1-byte value [-128 - 127]: A value is sent as 1-byte value with a sign, e.g. actuating
value. No additional parameters available.
– Scene number: The parameter is used to link the channel with a scene number. No
additional parameters available.
– RTC operating mode: After actuating the control element the device switches to the
parameterized operating mode. No additional parameters available.
– Temperature: After the control element is actuated, the device sends the parameterized
temperature value. No additional parameters available.
– 2-byte value [-32768 - +32767]: A value is sent as 2-byte value with a sign, e.g.
actuating value or time difference. No additional parameters available.
– 2-byte value [0 - 65535]: A value is sent as 2-byte value without a sign, e.g. actuating
value or time interval. No additional parameters available.
– 2-byte floating point: A value is sent as 2-byte floating point value, e.g. a temperature
value, a time duration, a power or a consumption value. No additional parameters
available.
– 4-byte value [-2147483648 - 2147483647]: A value is sent as 4-byte value with a sign,
e.g. actuating value or time difference. No additional parameters available.
– 4-byte value [0 - 4294967295]: A value is sent as 4-byte value without a sign, e.g.
actuating value. No additional parameters available.
– 14-byte text: Makes it possible to send a text. No additional parameters available.
Saving input signal during blocking:
Options: Deactivated
Activated
See the explanation above.
– Temperature comparator: This function can be used to compare temperature values. The
following parameters are displayed:
Type of comparator:
Options: Temperature with a constant
2 temperatures
This function can be used to compare two temperatures. Or a temperature can be
compared with an internal specified temperature value (constant).
– Temperature with a constant: This function makes an input available with a 2-byte
communication object. On this object temperature telegrams are received and
compared, which are sent from a KNX temperature sensor for example.
The following parameters are displayed:
