Abbott ARCHITECT RHS - System Power and Card Cage Comparison

MODULE 4: POWER AND CIRCUIT BOARDS
4-8 ARCHITECT
®
RSH Service Training Guide
FOR INTERNAL USE ONLY 201532-102
ARCHITECT i2000
SR
®
System and the ci8200
®
System
On the i2000
SR
and ci8200
®
Systems power originates at the i2000
SR
power supply. Power and control to
subassemblies on the RSH is provided by the i2000
SR
Card Cage. The i2000
SR
Card Cage houses and
utilizes the same three boards for the same RSH power and control as used on the c8000
®
System (refer to
page 3-7). Additionally, the i2000
SR
Card Cage contains several boards that are interchangeable for
troubleshooting purposes. These are the Indexer Boards, Motor Controller Boards, the RSH and PM
Controller boards.
NOTE: All Indexer Boards are interchangeable, as well as, Motor Driver Boards. The
RSH Controller and Module Controller Boards can also be interchanged for
troubleshooting. For additional information refer to the ARCHITECT i2000
SR
System and RSH Service and Support manuals.
