MODULE 2: BASIC OPERATION
ARCHITECT
®
RSH Service Training Guide 2-27
201532-102 FOR INTERNAL USE ONLY
RSH Keypad
The RSH has a keypad for user input. This is an alternate command mode of interaction to the touchscreen
and keyboard.
Component Description
Sample Handler Keypad • Extended System Control Center functionality
- Start, Pause or Stop
1 Run Key Moves the sample handler into the
running state.
2 Pause Key Pauses the sample handler.
3 Stop Key Stops the sample handler.
