Abbott ARCHITECT RHS - Carrier Transport Motor Drive; Carrier Pulley Assembly; Carrier Transport Bearing

MODULE 2: BASIC OPERATION
ARCHITECT
®
RSH Service Training Guide 2-25
201532-102 FOR INTERNAL USE ONLY
Carrier Transport Assembly
Carrier Transport
Carrier Arm
Carrier Transport Bearing
Carrier Pulley Assembly
Carrier Transport Motor Drive
Spring
Pulley
Side View
Bolt
(Right end)
(Left end)
Locking Wheel
