MODULE 5: MISCELLANEOUS
ARCHITECT
®
RSH System Service Training Guide 5-11
201532-102 FOR INTERNAL USE ONLY
Diagnostic Tips:
• Pipettor calibration failures can be caused by:
- LLS Antenna problems: poor connections at the antenna or card cage, LLS antenna
failure
- LLS Board problems: poor connection of the board in the card cage, board failure
- STAT iSample only, sample handler problems: carrier is not being moved to the
aspiration point correctly.
- Calibration targets not cleaned
- Probe failure
- RSH attached incorrectly to PM
- Left to right position is OFF
- Reference line on i2000
SR
®
System or leveling procedure incorrectly
performed
• Transport calibration failures can be caused by:
- Poor cable connections at the transport or SIB board
- Carrier Transport failure
- Slot damaged or obstructed
- Obstruction in Carrier Transport movement
• RSH Bar Code Reader calibration failures can be caused by:
- RSH Bar Code Reader failure
- Incorrect positioning of calibration tools
- Poor cable connections at the Bar Code Reader, SIB, or Card Cage
- Carrier Transport movement problem
