MODULE 4: POWER AND CIRCUIT BOARDS
4-12 ARCHITECT
®
RSH Service Training Guide
FOR INTERNAL USE ONLY 201532-102
Miscellaneous RSH Power Distribution
Power is distributed to three additional main RSH areas for use. They are:
• Carrier Positioner Assembly
• Carrier Transport Assembly
• Sensor Interface Board (SIB)
Carrier Positioner Assembly
The Carrier Positioner Assembly receives and delivers:
• +5VDC to the Encoder Sensor
Each PM has one positoner. On the ci8200
®
System is important to properly connect the cables to the
correct PM to ensure proper positioner function.
NOTE: The Carrier Positioner Board is replaceable. For additional information refer
to the ARCHITECT RSH Service and Support manual.
Carrier Transport Assembly
The Carrier Transport Assembly receives:
• +5VDC for two boards and ten sensors
- Carrier Transport Flex Board:
- NOT replaceable
- contains many sensors for positioning and recognition
- Rail Guide Sensor Board:
- replaceable
- identifies when transport arm contains a Carrier
