MODULE 2: BASIC OPERATION
2-20 ARCHITECT
®
RSH Service Training Guide
FOR INTERNAL USE ONLY 201532-102
Bar Code Reader System
The RSH contains a Sample Bar Code Reader located on left side of system by Priority Bay
CAUTION: Class 2 Laser Radiation. Avoid eye exposure to laser light. DO NOT
STARE INTO BEAM. Failure to follow proper procedures may result in a
potentially hazardous condition. Follow safety practices.
RSH Bar Code Configuration
Sample bar code symbologies for Positive Sample ID Testing are configured through the SYSTEM ICON,
SYSTEM Settings configuration screen. The RSH Bar Code Reader recognizes four types of bar code
symbologies:
• Code 39
• Codabar
• Interleaved 2 of 5
• Code 128 subset, A, B and C
The screen allows the operator (depending on the type of symbology used) to:
• Enable the Bar Code
• Use and/or send Checksum
• Send Start/Stop characters
• Configure Bar Code character lengths
NOTE: Code 128 does not require any configuration and is always enabled.
To view the Sample Bar Code settings:
1. Select Sample Bar Code Reader from the System Settings, System Categories list in the
Configuration screen.
2. Select F5 - Details.
The Details for bar codes window displays.
3. Select the Bar code type list button, and then select the desired bar code type.
NOTE: Refer to the procedure located in the ARCHITECT Operation Manual Section
2 Installation.
