Abbott ARCHITECT RHS - Procedures

MODULE 5: MISCELLANEOUS
ARCHITECT
®
RSH System Service Training Guide 5-13
201532-102 FOR INTERNAL USE ONLY
Procedures
Sensor and or installation related procedures include the following:
NOTE: For additional information refer to the RSH System Service and Support
Manual, Technical Service Bulletins, Instrument Service Advisories, and/or
the ARCHITECT System Operations Manual.
Procedure
M or D
FUNCTION and USE When to Perform
3710 Keypad Test D • (SSH and RSH) Sample Handler keypad
function is tested during this procedure.
• Install
• Troubleshooting
3400 Interlock Sensor Test D • All interlock sensors for the Processing
Module and the Sample Handler are checked
during this procedure.
• Install
• Troubleshooting
3401 Section/Bay Sensors Test D • This procedure tests the carrier/tray sensors for
priority and routine bays.
• Install
• Troubleshooting
5507 RSH Indicator Lights Test D • For RSH only
Use this procedure to test the RSH indicator
lights.
• Install
• Troubleshooting
Procedure
Name FUNCTION and USE When to Perform
P-01 Routine Bay Partition
Alignment
• To improve the quality of tray insertion by
adjusting the gap between the RSH standard bay
partitions
• Install
• Troubleshooting
