MODULE 4 - POWER AND CIRCUIT BOARD ACTIVITY
Power and Circuit Board Procedures
 Measure voltages on the Sensor Interface Board (2.6 Block/Functional Diagrams) and Record
recovered voltages in the table below.
Card Cage Cabling
a. List the components that receive 5VDC from the SIB.
Test P o i n t Expected MEASURED Comments
TP1 5VDC 4-5VDC
TP2 GND -
TP3 5VDC 4-5VDC
TP4 5VDC 4-5VDC
TP5 GND N/A
Fuse Expected MEASURED Rating (Amp)
F1 5VDC 4-5VDC 1.5A
F2 5VDC 4-5VDC 1.5A
F3 5VDC 4-5VDC 4.0A
F4 5VDC 4-5VDC 4.0A
F5 5VDC 4-5VDC 4.0A
F6 3.3VDC 3-3.3VDC 1.0A
F7 5VDC 4-5VDC 1.5A
F8 3.3VDC 3-3.3VDC 1.0A
F9 5VDC 4-5VDC 1.5A
F10 3.3VDC 3-3.3VDC 1.0A
RSH Bar Code Reader
RSH Keypad
PLSB and UDBs
Carrier Positioner Board
Carrier Transport Sensors
Low Voltage Regulator
Input DC/DC
