INTRODUCTION
16 ARCHITECT
®
RSH Service Training Guide
FOR INTERNAL USE ONLY 201532-102
Laser Light
Laser classification schemes are used to describe the capability of the laser or laser system to cause injury
to personnel. The higher the classification number, the greater the potential hazard. The lasers on the RSH
System emits a Class 2 laser radiation.
When these products are used according to its operating instructions, the laser does not present a hazard to
the eyes. Never stare directly into the beam, look into the aperture, place any optics into the beam or
bypass interlocks. Failure to follow proper procedures may result in an eye injury.
Only Abbott trained personnel or Service Personnel should remove the inner protective covers that enclose
the embedded laser.
Do not remove, damage or obliterate any of the laser warning labels. If any label becomes illegible, replace
it.
Proper warning wording and labeling:
Laser Caution Labels
Laser Aperture Label
• RSH (Retest Sample Handler), the label below affixed above the Sample Bar Code Reader under the priority bay
cover
Laser Class Wording Figure
1 CLASS 1 LASER PRODUCT Figure 1
2 LASER RADIATION
DO NOT STARE INTO BEAM
Figure 2
Figure 1
Figure 2
