Abbott ARCHITECT RHS - Processing Module Calibrations

MODULE 5: MISCELLANEOUS
5-10 ARCHITECT
®
RSH Service Training Guide
FOR INTERNAL USE ONLY 201532-102
Processing Module Calibrations
Calibrate Processing Module Pipettors.
Procedure
M or D
FUNCTION and USE Calibrates
1111 Sample
Pipettor Calibration
M
For i2000
SR
®
System ONLY
• Probe Straightness is determined.
• Positions are set for Sample Carriers, or
LAS Sample Carousel Wash station, RV1
and RV24.
• Sample Pipettor to Wash Cup
• Process Path to Position 1
• Process Path to Position 24
• Aspiration Location at RSH
1117 STAT Pipettor
Calibration
M For i2000SR
System ONLY
• STAT positions are set for Sample
Carriers, Wash Station, and RV 47.
• STAT Pipettor Wash Cup
• Process Path Position 47
• STAT aspiration location at RSH
1120 Sample
Pipettor Calibration
M
For c8000
®
System ONLY
• Sample Pipettor Calibration.
• automatically determines the position of
calibration targets in relation to the home
position of the pipettor.
• Sample Handler Carrier Position
• Reaction Carousel
• Sample Carousel
• Wash Cup
