MODULE 4: POWER AND CIRCUIT BOARDS
4-24 ARCHITECT
®
RSH Service Training Guide
FOR INTERNAL USE ONLY 201532-102
Use the Procedures located in the RSH Service and Support Manual, Procedures Section
and information in the Troubleshooting Section to perform the activity below:
2. Perform key Procedures:
 Measure voltages on the Sensor Interface Board (2.6 Block/Functional Diagrams) and
Record recovered
voltages in the table below.
Card Cage Cabling
Use the ARCHITECT RSH System Service and Support Manual, Troubleshooting section
to perform the activity below.
1. Locate the c8000
®
System power cables on the SMD/SH Power Supply.
2. Identify the cable routing from the c8000 System SMD/SH Power Supply to the RSH Card Cage for:
 5VDC
 +12VDC
 36VDC
a. List the components that receive 5VDC from the SIB.________________________
____________________________________________________________________
____________________________________________________________________
____________________________________________________________________
(Continued)
Test Point Expected MEASURED Comments
TP1 5VDC
TP2 GND
TP3 5VDC
TP4 5VDC
TP5 GND
Fuse Expected
MEASURED
Rating (Amp)
Side 1 Side 2
F1 5VDC
F2 5VDC
F3 5VDC
F4 5VDC
F5 5VDC
F6 3.3VDC
F7 5VDC
F8 3.3VDC
F9 5VDC
F10 3.3VDC
