Abbott ARCHITECT RHS - Carrier Positioner Carriage; Carrier Positioner Drive Assembly

MODULE 3: ROBOTICS
ARCHITECT
®
RSH System Service Training Guide 3-15
201532-102 FOR INTERNAL USE ONLY
Carrier Positioner Carriage
Teflon foot
encoder track
Encoder Sensor Top View
Motor Coupler
Carriage Block
Encoder Sensor
Carrier Positioner Drive Assembly
