Abbott ARCHITECT RHS - Component Removal and Replacement; Key Procedures

MODULE 2: BASIC OPERATION
2-30 ARCHITECT
®
RSH Service Training Guide
FOR INTERNAL USE ONLY 201532-102
Component Removal and Replacement
Use the information located in the RSH Service and Support Manual, Removal and
Replacement section to perform the activity below.
1. Remove and Install key components:
• Power OFF the PM.
• Locate and REMOVE the following components
 Status Indicator Light R&R W1.08
 Carrier/Tray Sensor R&R W1.09
• REINSTALL all removed components.
Key Procedures
Use the Procedure located in the ARCHITECT RSH Service and Support Manual,
Procedures section to perform the activity below.
1. Perform key Procedures:
 Perform - Interlock Sensor Override on RSH Covers
NOTE: Ensure Power is OFF to prevent SIB damage.
•Power ON
• Perform STARTUP
a. Observe LEDs on the Transport Assembly in Home vs. Maintenance position.
- Diagnostics/RSH radio button/1162 Carrier Transport Move
b. List the LEDs located on the Transport Assembly:
NOTE: There are 10 LEDs.
List LEDs:__________________________________________
__________________________________________
__________________________________________
__________________________________________
__________________________________________
__________________________________________
__________________________________________
__________________________________________
__________________________________________
__________________________________________
END OF BASIC OPERATION TROUBLESHOOTING ACTIVITY
