Abbott ARCHITECT RHS - Robotic System Activity; Components

APPENDIX
ARCHITECT
®
RSH System Service Training Guide A-7
201532-102 FOR INTERNAL USE ONLY
MODULE 3 - ROBOTIC SYSTEM ACTIVITY
Components
• LOCATE (Do Not remove) the components shown below and write the name of the component in
the space provided:
M
L
Rail Guide
Theta home & Theta align
X Home Sensor
Z Home Sensor
Z align Sensor (middle)
Z align Sensor (lower)
Section Align Sensor
Section Carrier Detect Sensor
Sensors
Carrier Positioner
Carrier Detect Sensor
Carrier Positioner Align Sensor
Carrier Transport Bearing
Assembly
Carrier Transport Belt
