MODULE 4: POWER AND CIRCUIT BOARDS
ARCHITECT
®
RSH Service Training Guide 4-23
201532-102 FOR INTERNAL USE ONLY
POWER & CIRCUIT BOARD TROUBLESHOOTING ACTIVITY
Upon completion of this activity, you should be able to:
• Locate Card Cage and other instrument circuit boards.
• Interpret Card Cage and circuit board data and use it to isolate the root cause of failure
WARNING: Potential for electric shock. Follow electrical safety practices.
Necessary Materials
• Service Tools and Digital Multimeter
Time 90 minutes
Activity
Component Removal, Replacement, Identification and procedures
Use the Removal and Replacement procedure located in the ARCHITECT RSH Service
and Support Manual, Removal and Replacement section, to perform the activity below.
1. Remove, and/or locate key components:
• LOCATE (DO NOT remove) the following components:
RSH Card Cage
SIB
Sample Handler Controller Board
Indexer Board
Motor Driver Board
Carrier Positioner Sensor Board
(Continued)
