APPENDIX
A-10 ARCHITECT
®
RSH Service Training Guide
FOR INTERNAL USE ONLY 201532-102
1. What position should the Transport Carrier be in when it is removed and why does in need to be in this
position?
The Transport Carrier is required to be in the furthest left position of the RSH to
protect and prevent damage to the Section Align Sensor.
2. List the replaceable parts on the Carrier Positioner Assembly:
Encoder Sensor and Cable
Positioner Board
Carriage
Positioner Drive Assembly
Positioner Cover
3. When reinstalling the Transport Bearing Assembly saturate the felt wiper pads with SuperLube Oil.
Carefully position the bearing on the rail
and depress the felt wiper pads as you guide them in the rail
to prevent damage.
4. Describe the purpose of the Carrier Positioner Assembly Encoder Sensor.
The Encoder Sensor tracks the Carrier Positioner Carriage movement
5. List all 36VDC RSH Motors:
X-Axis Drive Motor
Transport Motor Assembly
Carrier Positioner Drive Assembly motor
Carrier Transport Z motor
Carrier Transport Theta motor
6. What assembly applies tension to the Carrier Transport Belt?
Carrier Transport Pulley Assembly
