MODULE 2: BASIC OPERATION
2-28 ARCHITECT
®
RSH Service Training Guide
FOR INTERNAL USE ONLY 201532-102
M&D PROCEDURES
M & D procedures are grouped in two separate screen sections under the SYSTEM Menu, Diagnostics and
Maintenance. The procedures in each section are grouped by module type, and then by category. The
ARCHITECT
®
RSH Service and Support Manual provides guidance regarding module, category, user
logon, time required, along with a brief description of each procedure.
The DIAGNOSTIC screen displays the available diagnostic procedures. Depending on user logon,
available Diagnostic Procedures vary. Each category is represented by a tab on the Diagnostics screen.
Once a procedure is initiated, step-by-step instructions walk the user through completion.
Maintenance procedures are either scheduled or unscheduled. Each maintenance category is represented
by a tab on the screen. Once a procedure is initiated, step-by-step instructions walk the user through
completion. The user can also access windows to view version and detail information for each procedure
and print the procedure report.
NOTE: For additional information regarding M&D procedures refer to the
ARCHITECT RSH System Service and Support Manual and the ARCHITECT
System Operations Manual.
Below is a listing of M&D Procedures:
Procedure M or D FUNCTION and USE When to Perform
5507 RSH Indicator Lights Test D • Tests the RSH indicator lights. • Troubleshooting
6311 RSH Cleaning M • Provides instructions for cleaning the
following RSH components (RSH only):
- Tray bays
- Priority sections
- Carrier transport arm and guard
- RSH covers
- Carrier positioner
• Troubleshooting
• As Needed Maintenance
3252 RSH Bar Code Reader
Test
D • Moves Carrier from a bay and section to
the bar code reader where Carrier and
sample tubes are read.
• Troubleshooting
1119 Transport Calibration M • Aligns the Carrier Transport to the bays
and Carrier Positioner.
• In addition, the Carrier Positioner back
lash and pitch are calculated.
• Troubleshooting
