MODULE 4: POWER AND CIRCUIT BOARDS
4-10 ARCHITECT
®
RSH Service Training Guide
FOR INTERNAL USE ONLY 201532-102
The i2000
SR
Card Cage receives and distributes the following voltages for RSH functions:
Received Voltage Supplied Voltage Fuses
+5VDC • Sensor Interface Board (SIB)
• Sample Handler Controller/CPU Board
• Indexer
• Motor Driver Board
• F9 (7.5A) - CPU
• F16 (10A) - SIB
• F13 (2A) - 5VDC
+
12VDC • Sensor Interface Board
• Sample Handler Controller/CPU Board
• Indexer
• Motor Driver Board
N/A
+36VDC • Motor Driver Board:
- Carrier Transport X axis motor
- Carrier Transport Theta motor
- Carrier Transport Z motor
• F14 (7.5A) - 36VDC
• F15 (2A) - 36VDC
To Next Page
