APPENDIX
A-14 ARCHITECT
®
RSH Service Training Guide
FOR INTERNAL USE ONLY 201532-102
1. In the table below, fill in the Voltage supplied by the RSH Card Cage to the indicated device/
component:
2. What voltages are developed and used on the SIB Board?
3.3VDC and 1.8VDC
3. If +5VDC power was not present at the SIB which components might be affected?
RSH Bar Code Reader
LUI Keypad
PLSB and UDB
Carrier Positioner Board
Carrier Transport Sensors
4. On a ci8200
®
System which Card Cage controls the RSH?
i2000
SR
®
System Card Cage
5. What boards are contained in the RSH Card Cage on a c8000
®
Standalone System?
Module Controller or CPU
Indexer
Motor Driver
Component Voltage
SIB 5
Carrier Transport X Motor 36
Indexer 5,+ 12
