APPENDIX
A-16 ARCHITECT
®
RSH Service Training Guide
FOR INTERNAL USE ONLY 201532-102
4. Identify the components labeled in the picture below:
END OF MODULE
A: Carrier Transport Arm B: Carrier Transport Assembly
C: X Axis drive Motor or Carrier Transport Drive Motor D: Carrier Positioner Assembly section 4
E: Bar Code Reader F: Priority Bay
G: Sample Carrier H: Carrier/Tray Sensor
J*: Carrier Tray K: Routine Bay
L: Transport Pulley Assembly M: Flex Chain, Flex Cable or IGUS Chain
*Note: there is no I in the diagram below
