5-99 Service and Maintenance
7. Attach the four (4) screws to secure the LCD panel to the LCD cover.
Figure 5:150. Securing the LCD Panel Screws
8. Install the LCD bezel (see LCD Bezel Installation on page 5-87).
Table 5:15. LCD Bezel Screws
Screw Name Screw Type Quantity
M 2.5 x 4.0 4
