Service and Maintenance 5-30
Keyboard Removal
Prerequisite:
Battery Pack Removal on page 5-7
1. Using a plastic pry, push the six (6) latches circled below to slightly release the keyboard from
the upper case.
Figure 5:38. Releasing the Keyboard Latches
2. From the top side of the keyboard, pull the keyboard to detach it from the upper case.
Figure 5:39. Removing the Keyboard
CAUTION:
A cable is connected underneath the keyboard. Do not completely lift the keyboard.
