Acer Aspire E1-521 - WLAN Module Installation

Service and Maintenance 5-28
WLAN Module Installation
1. Connect the WLAN module to the mainboard connector.
Figure 5:35. Connecting the WLAN Module Connector
2. Attach the screw to secure the WLAN module.
Figure 5:36. Securing the WLAN Module Screw
