Jumper and Connector Locations 3-5
USB Board View
Figure 3:3. USB Board
Table 3:3. USB Board Jumper and Connectors
Item Description
JUSB2 USB Connector
JUSB3 USB Connector
JUSB2
JUSB3
Bottom View Top View
