Acer Aspire E1-521 - Upper Case Installation

Service and Maintenance 5-38
Upper Case Installation
1. Align the top side of the upper case to the lower case.
Figure 5:51. Installing the Upper Case (1 of 2)
2. Push to secure the upper case latches.
Figure 5:52. Installing the Upper Case (2 of 2)
