Jumper and Connector Locations 3-6
Power Board View
Figure 3:4. Power Board
Table 3:4. Power Board Jumper and Connectors
Item Description
SW2 Power Switch
LED3 Power LED
JPWR1 Power FFC Connector
LED3
SW2
JPWR1
Top View
Bottom View
