FRU (Field Replaceable Unit) List 6-9
FRU List
Category Description Part No.
BOARD
Liteon Wireless LAN Atheros HB125 1x1 BGN NI.23600.086
Foxconn Wirelss LAN Atheros HB125 1x1 BGN NI.23600.085
Foxconn Wirelss LAN Broadcom 4313 IPA 1x1 BGN NI.23600.090
POWER BOARD W/ FFC 55.M09N2.001
USB BOARD W/ FFC 55.M09N2.002
ODD BOARD 55.Y1GN2.001
CABLE
ANTENNA WLAN - MAIN 50.M09N2.003
ANTENNA WLAN - AUX 50.M09N2.004
LVDS CABLE 50.M09N2.005
EDP CABLE 50.M09N2.006
TP FFC 50.M09N2.001
DC-IN CABLE 65W 50.M09N2.002
DC-IN CABLE 90W 50.M0DN2.001
POWER CORD 1M SOUTH AFRICA 27.RJW02.001
POWER CORD 1M AUSTRALIA 27.RJW02.002
POWER CORD 1M EU 27.RJW02.003
POWER CORD 1M DENMARK 27.RJW02.004
POWER CORD 1M ISRAEL 27.RJW02.005
