FRU (Field Replaceable Unit) List 6-4
Table 6:1. Main Assembly Exploded Diagram
No. Description P/N
1 KEYBOARD NK.I1713.02L
2 UPPER CASE 60.M09N2.001
3 MAINBOARD NB.C0Y11.001
4 FAN 23.Y1GN2.001
5 THERMAL MODULE 60.Y1GN2.001
6 USB BOARD WITH FFC 55.M09N2.002
7 DC-IN CABLE 50.M09N2.002
8 SPEAKER L 23.M09N2.003
9 SPEAKER R 23.M09N2.002
10 ODD BOARD 55.Y1GN2.001
11 LOWER CASE 60.M09N2.002
