1-19 Hardware Specifications and Configurations
BIOS
LAN Interface
Keyboard
Item Specification
BIOS vendor Insyde
BIOS Version 1.00
BIOS ROM type W25Q32BV, EN25Q32B
BIOS ROM size 4MB
Features
• Insyde code base
• Flash ROM 4 MB
• Support ISIPP
• Support Acer UI
• Support multi-boot
• Suspend to RAM (S3)/Disk (S4)
• Various hot-keys for system control
• Support SMBIOS 2.3, PCI2.2.
• DMI utility for BIOS serial number configurable/asset tag
• Support PXE
• Support WinFlash
• Wake on LAN from S3
• Wake on LAN from S5 in AC mode
• System information
• Refer to Acer BIOS specification.
Item Specification
LAN Chipset Atheros AR8151L-B GbE LAN Controller
LAN connector type RJ45
LAN connector location JRJ45 at the left side
Features Supports 10/100/1000BASE-T GbE
Item Specification
Type TM7T_G11B
Total number of keypads 105-US/106-UK /109-JP keys
Windows logo key Yes
Internal & external keyboard
work simultaneously
Plug USB keyboard to the USB port directly: Yes
Features
• Phantom key auto detect
• Independent numeric keypad
• Support reverse T cursor keys
• Factory configurable different languages by OEM customer
