1-29 Hardware Specifications and Configurations
System Power Management
Card Reader
Item Specification
Mech. Off (G3) All devices in the system are turned off completely.
Soft Off (G2/S5)
OS initiated shutdown. All devices in the system are turned off
completely.
Working (G0/S0)
Individual devices such as the CPU and hard disk may be
power managed in this state.
Suspend to RAM (S3)
• CPU Set Power Down
• VGA Suspend
• PCMCIA Suspend
• Audio Power Down
• Hard Disk Power Down
• CD-ROM Power Down
• Super I/O Low Power mode
Save to Disk (S4)
Also called Hibernation Mode. System saves all system states
and data onto the disc prior to power off the whole system.
Item Specification
Chipset Realtek RTS5209
Package 48pin LQFP package
Maximum supported size
• xD: 2GB
• Multi Media Card: 512MB
• RS-MMC Card: 1GB
• MMC4.0 Card: 2GG, 4GB
• SD Card: 8GB
• SDHC Card: 32GB
• Mini SD Card: 2GB
• Micro SD Card: 8GB
• SDXC Card:64GB
• Memory Stick Card: 256MB
• Memory Stick Duo Card:128MB
• Memory Stick PRO Card: 4GB
• Memory Stick PRO Duo Card: 8GB
• M2 Card: 4GB
• Memory Stick Pro HG Duo:16GB
• Memory Stick Pro HG Duo micro: 16GB
Features
• Compliant with PCI Express Base Specification Revision
1.1
• Support 1-Lane 2.5Gbps PCI Express Bus
• Support 93C46 EEPROM
• Compliant with SD Part 1 Physical Layer Specification
Version 3.01
• Compliant with SDIO Specification Version2.00
