Connect the DUT input with the frequency output module of the calibrator, as shown in the Figure 21.
2. Create the task
Create the corresponding DUT tasks as described above and fulfill the necessary information. See table below.
Table 32 Flow volume totalizers task setting
Subject Valid value Description
Name Numbers, letters, symbols Task name
S/N Numbers, letters, symbols Task S/N
Model Numbers, letters, symbols Model of DUT
Frequency Numbers Frequency of DUT input signal
Amplitude Numbers Amplitude of DUT input signal
Flow unit Option Flow unit of DUT, variety of flow units available
Decimals Option 0~3 The last decimal digit of the DUT’s display
Total flow Numbers Expected total flow when the task finish
K-Param Numbers K coefficient of DUT (The flow rate represented by each signal pulse)
Tolerance Numbers Tolerance of DUT
Owner Numbers, letters, symbols Owner of DUT
Location Numbers, letters, symbols Location of DUT
Note Numbers, letters, symbols Additional information
