Additel 226Ex - Calibrating Temperature Devices; Delta- Pressure Flowmeters

90
1. Connect to DUT
 Refer to Figure 19 or 20 and the type of reference sensor to measure the TC or RTD. Then refer to Figure 7 to
measure the switch signal.
2. Create the task
Refer to paragraph 6.2.4.
3. Task setting
Refer to the task setting in paragraph 6.1.1.
4. Start the task
 For part of the content, refer to “Start the Task” in paragraph 6.1.1.
 When the DUT moves (open/close) during the task, the calibrator will automatically record the temperature value
at the moment of the action, without manual input.
5. Finish the task
Refer to “Finish the Task” in paragraph 6.1.1.
6.3 Calibrate temperature devices
6.3.1 Delta- pressure flowmeter
1. Connect DUT
 Connect the external pressure module to the module Lemo port A or B.
 Connect DUT output with the electrical module of the calibrator according to the signal type of DUT output
