Location Numbers, letters, symbols Location of DUT
Note Numbers, letters, symbols Additional information
3. Task setting
Refer to the task setting in paragraph 6.1.1.
4. Start the task
For part of the content, refer to Start the task in paragraph 6.1.1.
During the task performing, users need to manually control the electrical signal corresponding to the DUT output
according to the set point and input the reading of the DUT electrical signal into the calibrator, the calibrator will
give the task result according to the measured value and entered reading as well as the accuracy analysis set by
users.
5. Finish the task
Refer to Finish the task in paragraph 6.1.1.
6.4.4 Limit Switches
1. Connect to DUT
Connect the DUT input with the output module of the calibrator, as shown in figure 22 (for current output) or 21
(for voltage output).
Connect the DUT output with the electrical module of the calibrator, as shown in Figure 7.
