Additel 226Ex - Signal Measure Specifications (Environmental Temp.: 20±10℃, 1 Year Accuracy)

12
1.2.2 Signal measure specification (Environmental temp.: 20±10℃, 1 year accuracy)
Table 3 Signal measure specification
Specifications Range Resolution Accuracy
Voltage
(-300～300)mV
1μV 0.01%RD+15μV
(-30～30)V
0.1mV 0.01%RD+1.5mV
Current ±30mA 0.1μA 0.01%RD+1.5μA
Frequency
(0.01～5)Hz
Auto range, 6-digit
0.002%RD+0.00002Hz
(5～50)Hz
0.002%RD+0.0002Hz
(50～500)Hz
0.002%RD+0.002Hz
(500～5000)Hz
0.002%RD+0.02Hz
(5000～50000)Hz
0.002%RD+0.2Hz
Pulse
0～9999999
1 NA
TC
(-10～75)mV
0.1μV 0.01%RD+3.0μV
Internal
CJC temperature
NA NA
±0.15°C (-10°C～50°C assured)
RTD
(0～400)Ω
1mΩ 0.01%RD+20mΩ
(0～4000)Ω
10mΩ 0.01%RD+200mΩ
Barometric
(60～110)kPa.a
NA Annual accuracy: ±55Pa
Switch Supports dry or wet switches. Voltage range of 3 to 30 V. Response speed < 10 ms
