98
Owner Numbers, letters, symbols Owner of DUT
Location Numbers, letters, symbols Location of DUT
Note Numbers, letters, symbols Additional information
3. Task setting
Refer to the task setting in paragraph 6.1.1.
4. Start the task
For part of the content, refer to Start the task in paragraph 6.1.1.
During the task performing, the calibrator will output the corresponding electrical signal according to the set point
and the DUT input type (current/voltage) set by the user. For the measured value at each set point, users need to
manually input them.
5. Finish the task
Refer to Finish the task in paragraph 6.1.1.
6.4.2 Loop signal source
1. Connect to DUT
Connect the DUT with the measurement module of the calibrator, as shown in the figure 8 (for current
measurement) or 7 (for voltage measurement).
2. Create the task
Create the corresponding DUT tasks as described above and fulfill the necessary information. See table below.
