Additel 226Ex - Page 110

99
Table 35 Loop signal source task setting
Subject Valid value Description
Name Numbers, letters, symbols Task name
S/N Numbers, letters, symbols Task S/N
Model Numbers, letters, symbols Model of DUT
Range (4~20)mA,(0~10)mA,(0~20)mA,(1~5)V,(0~5)V,(0~10)V, custom Output range of DUT
Accuracy 0.025%,0.05%,0.1%,0.16%,0.25%,0.4%,1%,1.6%,2.5%,4%,custom Accuracy of DUT
Transfer function Linear / square / square root Transfer function of the DUT
Owner Numbers, letters, symbols Owner of DUT
Location Numbers, letters, symbols Location of DUT
Note Numbers, letters, symbols Additional information
3. Task setting
Refer to the task setting in paragraph 6.1.1.
4. Start the task
 For part of the content, refer to Start the task in paragraph 6.1.1.
 During the task performing, the calibrator will output electrical signals according to the set point and measure the
DUT output signal, no manual input required during the process.
5. Finish the task
