73
2
）
Click to go to the next point.
3
）
Repeat step 1 and 2 until the whole task is finished.
5. Finish the task
After the task is finished, the task report will automatically pop up. In the task report page, you can view the detailed
data of each set point. Click the save button at the bottom right of the interface to fill out in the information
required, and save the task data of the result, as shown below.
Table 23 Save task data setting
Subject Valid value Description
Operator Numbers, letters, symbols Information for operator
Date and time Valid date and time Date and time of the task performing
Temperature
Number (℃)
Ambient temperature when task performing
Humidity Number (%RH) Ambient humidity when task performing
Save as As found/ As left/ both Task data type
6.1.2 Pressure transmitter
1. Connect to DUT
Connect the external pressure module to the LEMO port A or B.
As shown in the Figure 8 (current), 7 (voltage) or 11/12 (HART), connect the DUT output with calibrator’s electric
module according to DUT output signal type.
