2. Create a task
Create the corresponding DUT tasks as described above, and fill out the necessary information, as shown below.
Table 24 Pressure transmitter task setting
Subject Valid value Description
Name Numbers, letters, symbols Task name
Task No. Numbers, letters, symbols Task number
Model Numbers, letters, symbols Model of DUT
Pressure type GP / AP / DP Pressure type of DUT
Input range Numbers Input range of DUT
Output range
Analog signal:
4~20mA, 0~10mA, 0~20mA, 1~5V, 0~5V, 0~10V, custom
Output range of DUT
HART device: PV, percentage,
output current, loop current
Accuracy
0.05%, 0.1%, 0.2%, 0.5%,
1%, 1.5%, 2%, 2.5%, custom
Accuracy of DUT. If choosing custom, the input
number means the accuracy level of this pressure
transmitter.
Transfer function Linear / square / square root Transfer function of the DUT signal
Owner Numbers, letters, symbols Owner of DUT
Location Numbers, letters, symbols Location of DUT
Note Numbers, letters, symbols Additional information
